Need this key blank for this to work: B1110-P or B96-P
Option A
Originate New Master Key
1. Insert new key into ignition cylinder and turn it to the ON (RUN) position. The security light on the dash will illuminate and stay on for ten minutes.
2. When the security light goes out, you have one minute to start the next step. Turn the ignition cylinder to OFF and then back to the ON (RUN) position. The security light on the dash will illuminate and stay on for ten more minutes.
3. When the security light goes out, you have one minute to start the next step. Turn the ignition cylinder to OFF and then back on the ON (RUN) position. The security light on the dash will illuminate and stay on for ten more minutes.
4. After the security light has gone off the third time, the key has been programmed into the vehicle's computer and will operate the car. It has replaced ALL the previous electronic key codes and is the ONLY key programmed into the vehicle's computer.
Add Duplicate Key
1. Insert an existing key into the ignition cylinder.
2. Turn the ignition cylinder to ON (RUN) and back to OFF.
3. Remove the existing key and, within fifteen seconds, insert the new key and turn it to ON (RUN).
4. The security light will light up for two seconds to indicate success in programming the key into the vehicle.
If the Add Duplicate key instructions above did not work follow the variation below.
1. Insert already programmed key into ignition and START car.
2. Turn key off and remove key.
3. Insert key to be programmed and turn to ON within 15 seconds of removing the already programmed key.
4. The security light will go off once the key has been programmed.
5. Remove key and then test.
If the vehicle doesn't have a security light, leave the key in for 10 minutes and 30 seconds during step 4.
Option B
Originate New Master Key Master Keys must be used.
1. Make proper cuts onto a GM Master key.
2. Insert the new working key into the ignition cylinder and turn it to the ON position. The THEFT light will light up and stay on for about 10 minutes.
3. When the light goes out, repeat the same procedure as in step #2, two more times.
4. When the THEFT light goes out, the new key has been programmed.
To program the second key.
1. Within 20 seconds of completing the last step for the first key, insert a second Master key and turn to the ON position. When the light goes out, the new key is programmed.
2. Repeat the previous step for programming up to 12 additional keys.
Add Duplicate Key - Must have two programmed Sentry Keys
1. Insert the first working key into the ignition cylinder.
2. Turn the ignition cylinder to the ON position.
3. When the SECURITY light goes out, remove the key.
4. Insert the second working key and turn the ignition cylinder ON.
5. When the SECURITY light goes out, remove the key.
6. Insert the new duplicate key and turn the ignition cylinder ON.
7. When the SECURITY light goes out, key has been programmed.
